3 Phase Encoder Motor, 11kW, 6 Pole with Force Vent Fan

TECC3, IE3, 3 phase, 11kW, 6 pole, 160L frame encoder motor with force vent fan

£1,859.16 £1,549.30

TECC3, Cast Iron, 3 phase, 11kW, 6 pole, 160L frame IE3 motor fitted with a 5-30V incremental encoder and 400V 3 phase force vent fan

Encoder connection via 2m screened cable

Please allow 10-15 working days from order to despatch

B3 foot mount as standard

Select B34 foot & face mount or B35 foot & flange mount from the drop down box

Power kW 11

Power HP 15

Input Phases 3

Poles 6

Slip Speed 960rpm

Frame Size 160M

Model No TECC3-11-6-Enc-FVK

Frame Material Cast Iron

Shaft Diameter 42mm

Current 200V N/A

Current 400V 21.6Amps

Weight 88.000000

Width 290mm

Depth 748mm

Height 384mm

Input Volts Delta 400V

Input Volts Star 690V

Encl Rating IP55

Efficiency IE3 Motor

Duty S1

Mounting Type B3

Input Freq 50 / 60Hz

Max Temp 40 Deg C

Inverter Rated Yes

Approvals CE
