3 Phase Encoder Motor, 2.2kW, 2 Pole with Force Vent Fan
TECA3, IE3, 3 phase, 2.2kW, 2 pole, 90L frame encoder motor with force vent fan
£1,039.08
£865.90
TECA3, aluminium, 3 phase, 2.2kW, 2 pole, 90L frame IE3 motor fitted with a 5-30V incremental encoder and force vent fan
Encoder connection via 2m screened cable
Please allow 10-15 working days from order to despatch
B3 foot mount as standard
Select B34 foot & face mount or B35 foot & flange mount from the drop down box
Power kW
2.2
Power HP
3
Input Phases
3
Poles
2
Slip Speed
2850rpm
Frame Size
90L
Model No
TECA3-2.2-2-Enc-FVK
Frame Material
Aluminium
Shaft Diameter
24mm
Current 200V
8.91Amps
Current 400V
4.83Amps
Weight
23.800000
Width
183mm
Depth
458mm
Height
229mm
Input Volts Delta
200V
Input Volts Star
400V
Encl Rating
IP55
Efficiency
IE3 Motor
Duty
S1
Mounting Type
B3
Input Freq
50 / 60Hz
Max Temp
40 Deg C
Inverter Rated
Yes
Approvals
CE
