TECA, 3 phase, 0.09kW, 4 pole, IE1 Standard Efficiency Motor

TECA, aluminium frame, 3 phase, 0.09kW, 4 pole motor, 56 frame, IE1 motor

£52.92 £44.10

TECA, aluminium frame, 3 phase, 0.09kW, 4 pole motor, 56 frame, IE1 standard efficiency motor

B3 foot mount as standard

Select B34 foot & face mount or B35 foot & flange mount from the drop down box

Power kW 0.09

Power HP 0.12

Input Phases 3

Poles 4

Slip Speed 1360rpm

Frame Size 56

Model No TECA562-4

Frame Material Aluminium

Shaft Diameter 9mm

Current 200V 0.78Amps

Current 400V 0.45Amps

Weight 3.200000

Width 117mm

Depth 196mm

Height 156mm

Input Volts Delta 200V

Input Volts Star 400V

Encl Rating IP55

Efficiency IE1 Motor

Duty S1

Mounting Type B3

Input Freq 50 / 60Hz

Max Temp 40 Deg C

Inverter Rated Yes

Approvals CE
