TECA2, 3 Phase, 0.18kW, 2 pole, IE2 High Efficiency Motor
TECA2, aluminium frame, 3 phase, 0.18kW, 2 pole motor, 63 frame, IE2 motor
£61.32
£51.10
TECA2, aluminium frame, 3 phase, 0.18kW, 2 pole motor, 63 frame, IE2 motor
B3 foot mount as standard
Select B34 foot & face mount or B35 foot & flange mount from the drop down box
NOTE: The length of the newer IE2 motor may be longer than the older IE1 motor. Please check that you have no size constraints.
Power kW
0.18
Power HP
0.25
Input Phases
3
Poles
2
Slip Speed
2840rpm
Frame Size
63
Model No
T2A-631-2
Frame Material
Aluminium
Shaft Diameter
11mm
Current 200V
0.90Amps
Current 400V
0.52Amps
Weight
3.600000
Width
122mm
Depth
217mm
Height
172mm
Input Volts Delta
200V
Input Volts Star
400V
Encl Rating
IP55
Efficiency
IE2
Duty
S1
Mounting Type
B3
Input Freq
50 / 60Hz
Max Temp
40 Deg C
Inverter Rated
Yes
Approvals
CE
