CT Unidrive M300-05400270 11kW 400V 3 Phase - Service Ex
CT Unidrive M300-05400270 11kW 400V 3 Phase - Service Ex - Image 2
CT Unidrive M300-05400270 11kW 400V 3 Phase - Service Ex - Image 3

CT Unidrive M300-05400270 11kW 400V 3 Phase – Service Ex

Control Techniques Unidrive M300, 400V 3 phase input, 400V 3 phase output, 11kW, 27A, IP20.

£808.00
£969.60 (incVAT)

Enquire
SKU: M300-05400270 Categories: ,

Control Techniques Unidrive M300-05400270, 400V 3 phase input, 400V 3 phase output, 11kW, 27A, IP20

This is a service exchange product, new unused, this product carries a 1 month warranty from date of purchase.

Power kw
11
Power HP
15
Input Voltage
415V
Output Voltage
0 to 415V
Input Phases
3
Output Phases
3
Encl Rating
IP20
Output Current
27A
Input Current
26A
Width
143mm
Height
391mm
Depth
192mm
Weight
7.4kg
Frame Size
5
Overload
150%
Input frequency
48-62Hz
Output frequency
0-550Hz
Maximum temperature
40 Deg C
Digital inputs
4
Digital outputs
1
Analogue inputs
2
Analogue outputs
1
Output relays
1
Approvals
CE, UL
Control Type
Open loop vector, RFC-A, V/f
