TEC Gearmotor with brake, 3 phase, 15kW at 10 to 1
TEC IE3 premium efficiency 3 phase brake gearmotor, 15kW, 4 pole, 160L frame, coupled with a 10:1 ratio gearbox for reduced output speed and increased torque.
Designed for industrial applications requiring controlled motion, reliable braking, and high torque performance. Suitable for conveyors, processing equipment, handling systems, and heavy-duty machinery.
- 15kW 3 phase brake gearmotor
- IE3 premium efficiency motor
- 4 pole motor configuration
- 10:1 gearbox reduction ratio
- Integrated electromagnetic brake
- Aluminium frame motor construction
- Suitable for industrial continuous duty applications
£2,827.85
£3,393.42 (incVAT)
T3AB, Aluminium Frame, 3 Phase, 15kW, 4 pole, 160L Frame, IE3 Premium Efficiency Brake Motor coupled to a TCNDK150 at 10 to 1 ratio
AC to DC rectifier mounted in motor terminal box, brake fed from a two phase 400Vac supply.
Brake torque 185Nm. (The brake torque figures are factory set and cannot be adjusted).
Power kw
15
Input Voltage
400/690V
Input Phases
3
Poles
4
Frame Size
160/150
Encl Rating
IP55
Weight
157kg
Duty
S1
Output Speed
140rpm
Ratio
10:1
Approvals
CE
Model No
TECWGBM15-10
Mounting type
B3/B5
Input volts star
690V
Input volts delta
400V
Frame Material
Aluminium
Output Bore Dia
50mm
Output Torque
911.5Nm
Service Factor
1.33
Efficiency
IE3
Maximum temperature
40 Deg C
Current 200V
N/A
Current 400V
28.15A
Slip Speed
1460rpm
Inverter rated
Yes
